Geometrical properties of thermodynamic averages

Description

This treatment computes 0D and 2D geometrical properties of a 2D section resulting from a cut with a revolution surface around the x-axis of an axisymmetric configuration. The following picture illustrates the computed 0D properties:


The following picture illustrates the computed 2D properties:


Construction

import antares
myt = antares.Treatment('thermogeom')

Parameters

  • base: Base

    The input base on which geometrical properties will be computed. Read section Preconditions to know the assumptions on this base. This input base is modified in-place. Read section Postconditions for more details.

  • cartesian_coordinates: list(str), default= [‘x’, ‘y’, ‘z’]

    Ordened names of the cartesian coordinates.

  • cylindrical_coordinates: list(str), default= [‘x’, ‘r’, ‘theta’]

    Names of the cylindrical coordinates: the axis of rotation (axial coordinate), the distance to this axis (radius), and the azimuth.

  • def_points: list(tuple(float)), default= None

    List of coordinates of 2 points in the cylindrical coordinates system (only axis and radius). The first point gives the location of the hub. The second point gives the location of the shroud. These points do not necessarily belong to the hub nor to the shroud.

Preconditions

The treatment must be applied on a mono-zone base containing a 2D section resulting from a cut with a revolution surface around the ‘x’-axis of an axisymmetric configuration. This Zone must contain only one Instant (steady-state).

The specified coordinates must be available at nodes. The rotation axis is the Cartesian first component of cartesian_coordinates.

The pitch of the row(s) is necessary : it can be available as an attribute called ‘pitch’ in the zone in mono-row case, but must be available at cells in multi-row case.

Postconditions

The input base is modified in-place.

The base contains cartesian coordinates of normals, surfaces (see ‘base.compute_cell_normal’ for naming conventions) and cylindrical coordinates at cells (same name than cylindrical_coordinates) and h/H local to the surface (called ‘h_H’) at nodes. The base is extended with one attribute named ‘0D/Geometry’, which is a dictionary with variables:

  • Xmin, Rmin

    Coordinates (in the unit of the input data) of the hub point in the (x, r) plane.

  • Xmax, Rmax

    Coordinates (in the unit of the input data) of the shroud point in the (x, r) plane.

  • Veine

    Length (in the unit of the input data) between the hub and the shroud in the surface.

  • Angle

    Angle (in degrees) between the x-axis and the projection of the surface in the (x, r) plane.

  • Area

    The area (in the unit of the input data) of the surface on 360 degrees.

  • Blade_ratio

    Ratio of (in %) of the blade area on the surface with blades.

  • Normal_x, Normal_r

    Coordinates of a unit normal of the surface in cylindrical coordinates.

Main functions

class antares.treatment.turbomachine.TreatmentThermoGeom.TreatmentThermoGeom
execute()

Compute the geometrical values of thermodynamic averages.
